26
Installation RS20/22/30/32/40
Release
05
12/2015
1.1.2 Combination options for the RS40 device variants
The product designation of your device is made from combining the desired
product characteristics in accordance with the following table. The
corresponding short designation is in column 3.
Position Characteristic Ident. Property
1 to 4 Product RS40 Rail Switch with gigabit ports
5 - (hyphen) -
6 to 7 Number of 10/100
Mbit/s ports
00 0 × 10/100 Mbit/s Ethernet
8 and 9 Number of 1000
Mbit/s ports
09 9 × 1000 Mbit/s Ethernet
10 and 11 1. + 2. Uplink port CC 2 × Combo port multirate (SFP slot:
100/1000 Mbit/s; alternatively twisted pair RJ45
socket: 10/100/1000 Mbit/s)
12 and 13 3. + 4. Uplink port CC 2 × Combo Port multirate (SFP-slot:
100/1000 Mbit/s; alternatively twisted pair RJ45
socket: 10/100/1000 Mbit/s)
14 Temperature range S Standard: +32 °F to +140 °F (0 °C to +60 °C)
T Extended: -40 °F to + 158 °F (−40 °C to +70 °C)
E Extended: −40 °F to + 158 °F (−40 °C to +70 °C),
Conformal Coating
15 Voltage range D 9.6 V DC to 60 V DC or
18 V AC to 30 V AC
16 Approval A CE, UL 508, ISA 12.12.01 (UL 1604)
H CE, UL 508, GL, Railway (along track), Sub station,
ISA 12.12.01 (UL 1604)
B CE, UL 508, GL, Railway (along track), Sub station,
ISA 12.12.01 (UL 1604), Hazardous
Location/ATEX/IECEx
17 Software variant E Enhanced
P Professional
Table 5: Combination options for the RS40 device variants
