Installation RSPL 20/30
Release 04 02/2013
The Hirschmann network components help you ensure continuous
communication across all levels of the company.
1.2 Device name and product code
The device name corresponds to the product code. The product code is
made up of characteristics with defined positions. The characteristic values
stand for specific product properties.
Item Characteristic Character
istic value
Description
1 ... 4 Product RSPL Rail Switch Power Lite
5 ... 6 Data rate 20 Switch fast Ethernet
30 Switch with gigabit ports
7 (hyphen) –
8 ... 9 Number:
10
a
/100 Mbit/s ports
08 8 × (10/)100 Mbit/s ports
10 ... 11 Number:
10
b
/100/1000 Mbit/s
ports
00 0 × (10/)100/1000 Mbit/s ports
02 2 × (10/)100/1000 Mbit/s ports
12 ... 14 Configuration of the
uplink ports
2Z6 2 × SFP slot for 100 Mbit/s F/O connection
2O7 2 × (10/)100/1000 Mbit/s combo ports
15 ... 16 Configuration of the
other ports
TT 6 × RJ-45 socket for 10/100 Mbit/s twisted-
pair connection
YT 2 × SFP slot for 100 Mbit/s F/O connection
All others: RJ-45 socket for 10/100 Mbit/s twisted-
pair connection
ZT 4 × RJ-45 socket for 10/100 Mbit/s twisted-
pair connection
4 × SFP slot for 100 Mbit/s F/O connection
17 (hyphen) –
18 Temperature range S Standard +32 °F ... +140 °F (0 °C ...
+60 °C)
T Extended −40 °F ... +158 °F (−40 °C
... +70 °C)
E Extended with
conformal coating
−40 °F ... +158 °F (−40 °C
... +70 °C)
19 ... 20 Operating voltage CC 2 voltage inputs for redundant voltage supply
Rated voltage range DC
24 V ... 48 V Class 2
M9 1 voltage input
Rated voltage range AC
110 V ... 230 V, 50 Hz ... 60 Hz
Rated voltage range DC
110 V ... 250 V
Table 1: Device name and product code
