20
Installation
RSPL 20/30
Release
04
02/2013
1.4.2
Rear view
1.5
P
ow
er supply
1.5.1
Operating voltage type
M9
A 3-pin terminal block is ava
ilable to supply the device.
You will find more information on
page
30
.
1.5.2
Operating voltage type
CC
For the redundant supply of the devi
ce, two 2-pin terminal blocks are
available.
You will find more information on
page
31
.
1
Slot for the SD card
2
Knurled screw
1
2
19
21
