ON SCREEN DISPLAY
17
ON SCREEN DISPLAY
Whenever a function button (Stop, FF, etc.) is pressed, or when you change
channels, a 6 second OSD appears. The function name or the channel number (if
tuned) are displayed as a large overlay for 3 seconds, then again for 3 seconds in a
smaller overlay.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hitachi 20VR4B and is the answer not in the manual?

Hitachi 20VR4B Specifications

13VR3B

Display IconDisplay
picture tube size13 inches
VCR IconVCR
formatVHS
record/playback systemVideo: 4 heads, Audio: Monaural
tape speed33.35mm/sec(SP), 16.67mm/sec(LP), 11.12mm/sec(EP)
Power IconPower
power source120V AC, 60Hz
power consumptionApprox. 71W
Operating Environment IconOperating Environment
television systemEIA Standard NTSC color
channel coverage181 ch.
operating temperature41º F~104º F (5º C~40º C)
Weight and Dimensions IconWeight and Dimensions
height15 9/16 in.
width15 9/16 in.
depth14 3/4 in.
weight29.0 lbs.

20VR4B

Display IconDisplay
picture tube size20 inches
VCR IconVCR
formatVHS
record/playback systemVideo: 4 heads, Audio: Monaural
tape speed33.35mm/sec(SP), 16.67mm/sec(LP), 11.12mm/sec(EP)
Power IconPower
power source120V AC, 60Hz
power consumptionApprox. 89W
Operating Environment IconOperating Environment
television systemEIA Standard NTSC color
channel coverage181 ch.
operating temperature41º F~104º F (5º C~40º C)
Weight and Dimensions IconWeight and Dimensions
height19 7/8 in.
width20 1/2 in.
depth18 5/16 in.
weight52.0 lbs.
