VCR STATUS DISPLAY
18
VCR STATUS DISPLAY
As the Recall button is pressed, the sequence of overlays shown below will be
displayed as long as the finger appears in the lower right (for about the first 3
seconds). After the finger disappears, the overlay displayed will remain on the TV
screen until it is removed by the next press of the Recall button.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hitachi 20VR4B and is the answer not in the manual?

Hitachi 20VR4B Specifications

13VR3B

Display IconDisplay
picture tube size13 inches
VCR IconVCR
formatVHS
record/playback systemVideo: 4 heads, Audio: Monaural
tape speed33.35mm/sec(SP), 16.67mm/sec(LP), 11.12mm/sec(EP)
Power IconPower
power source120V AC, 60Hz
power consumptionApprox. 71W
Operating Environment IconOperating Environment
television systemEIA Standard NTSC color
channel coverage181 ch.
operating temperature41º F~104º F (5º C~40º C)
Weight and Dimensions IconWeight and Dimensions
height15 9/16 in.
width15 9/16 in.
depth14 3/4 in.
weight29.0 lbs.

20VR4B

Display IconDisplay
picture tube size20 inches
VCR IconVCR
formatVHS
record/playback systemVideo: 4 heads, Audio: Monaural
tape speed33.35mm/sec(SP), 16.67mm/sec(LP), 11.12mm/sec(EP)
Power IconPower
power source120V AC, 60Hz
power consumptionApprox. 89W
Operating Environment IconOperating Environment
television systemEIA Standard NTSC color
channel coverage181 ch.
operating temperature41º F~104º F (5º C~40º C)
Weight and Dimensions IconWeight and Dimensions
height19 7/8 in.
width20 1/2 in.
depth18 5/16 in.
weight52.0 lbs.
