SETTING THE VCR TO RECORD LATER
37
SETTING THE VCR TO RECORD LATER
You can record the program automatically, at the time you prefer. This case,
screen indication show you the way of operation at the time recording start.
We suggest you try all the different ways of programming the VCR when you
have some leisure time, so you can learn how it works. That way, when an
important show is going to be on that you really want to record, you'll be
confident that your timed recording setup will work.
Types of Delayed Recordings
ONE TIME Records one show at a particular date and time.
DAILY Records a show at the same time every day of the week, Monday
through Friday.
WEEKLY Records a show at the same day and time every week.
Your TV/VCR Combination can record up to 8 programs at different days and
times, or up to 8 programs on the same day.
Before You Begin
Assemble the information you need for timed recording:
• Be sure that the clock is set to the correct time.
• Date and day of the program.
• Starting time.
• Ending time.
• Channel to be recorded.
• Blank or erasable videocassette (safety tab intact)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hitachi 20VR4B and is the answer not in the manual?

Hitachi 20VR4B Specifications

13VR3B

Display IconDisplay
picture tube size13 inches
VCR IconVCR
formatVHS
record/playback systemVideo: 4 heads, Audio: Monaural
tape speed33.35mm/sec(SP), 16.67mm/sec(LP), 11.12mm/sec(EP)
Power IconPower
power source120V AC, 60Hz
power consumptionApprox. 71W
Operating Environment IconOperating Environment
television systemEIA Standard NTSC color
channel coverage181 ch.
operating temperature41º F~104º F (5º C~40º C)
Weight and Dimensions IconWeight and Dimensions
height15 9/16 in.
width15 9/16 in.
depth14 3/4 in.
weight29.0 lbs.

20VR4B

Display IconDisplay
picture tube size20 inches
VCR IconVCR
formatVHS
record/playback systemVideo: 4 heads, Audio: Monaural
tape speed33.35mm/sec(SP), 16.67mm/sec(LP), 11.12mm/sec(EP)
Power IconPower
power source120V AC, 60Hz
power consumptionApprox. 89W
Operating Environment IconOperating Environment
television systemEIA Standard NTSC color
channel coverage181 ch.
operating temperature41º F~104º F (5º C~40º C)
Weight and Dimensions IconWeight and Dimensions
height19 7/8 in.
width20 1/2 in.
depth18 5/16 in.
weight52.0 lbs.
