MEANINGS OF SYMBOLS
NOTE: Some units do not carry them.
Symbols
WARNING
The following show symbols used for the machine. Be sure that you understand their meaning before use.
It is important that you read, fully understand and
observe the following safety precautions and
warnings. Careless or improper use of the unit may
cause serious or fatal injury.
Off /Stop
Read, understand and follow all warnings and
instructions in this manual and on the unit.
Emergency stop
Always wear eye, head and ear protectors when using
this unit.
Fuel and oil mixture
Warning, kickback danger. Be careful of possible
sudden and accidental upward and/or backward
motion of the guide bar.
Chain oil fi ll
One-handed usage not permitted. While cutting, hold
chain saw fi rmly with both hands with thumb fi rmly
locked around front handle.
Carburetor adjustment - Idle speed
The chain saw is specially designed for tree service
and therefore shall be used by trained operators only,
in off -ground work in trees.
Carburetor adjustment - Low speed mixture
It is important that you wear the protective clothing for
feet, legs, hands and fore-arms.
Carburetor adjustment - High speed mixture
Chain brake Hot surface
Choke - RUN position (Open) Priming pump
Choke - START position (Close)
6
Guaranteed Sound power level
On/Start
Contents
WHAT IS WHAT? .............................................................................. 7
WARNINGS AND SAFETY INSTRUCTIONS .................................. 8
SPECIFICATIONS .......................................................................... 10
ASSEMBLY PROCEDURES ........................................................... 10
OPERATING PROCEDURES ......................................................... 11
MAI NT ENA NCE .............................................................................. 13
Parts breakdown
(Original instructions)
