Hitachi NV 75AG - Interchangeability of Parts

--- 11 ---
Body [18]
Dust Filter [33]
Gasket (B) [32]
Cylinder [15]
Plunger Spring [58]
Trigger [39]
Part NV 75AG NR 65AK
8-2. Interchangeability of Parts
The driving section and the magazine section of the Model NV 75AG have been newly designed and there is no
interchangeability with those of the Model NR 65AK. Although most parts of the output section and the control
valve section of the Model NV 75AG are interchangeable with those of the Model NR 65AK, there is no
interchangeability for the parts shown in the table below.
Bore diameter
is concaved.
Plunger (A)
Color: Black
Viewed from "A"
Air passage hole to
feed nails (3 mm dia.)
Upper end surface of
the cylinder
Dust Filter [33]
Grip rubber
Gasket (B) [32]
Viewed from "A"
Gasket (B)
Grip Tape (A)
Color: Yellow
Color: Silver
Color: Black
Plunger (A)
Upper end surface
of the cylinder
A
A
