Set Dimensions
A
B
C
DE
F
G
H
J
T
S
L
M
Units
I
K
R
Q
PO
N
Inches
mm
Inches 42 2-3/4 2-3/4 30-21/32 28-1/16
21-31/32 17-31/32 15-11/32 36-7/16 20-23/32 4-23/32 3-9/16 1-1/8 15-9/32 8-19/32 24-13/16 8-19/32 9-7/8 12-1/8 6-1/16
1067.00 70.5 70.5 779.15 713.00 558.32
456.15 390.00 926 526.60 119.50 90.80 28.70 388.38 218.50 630.00 218.50 251.00
308.00 154.00
42 Inch Models (Includes Table Top Stand) Weight (lbs./kg): TBD
Rear View, Use as Reference for Wall Mount Bracket
