Service Processor
The VSP G130 include an optional, separate 1U service processor (SVP) dedicated to host
an element manager (Storage Navigator). The SVP operates independently from the CPU
of the storage system and operating system, and provides out‑of‑band conguration and
management of the storage system. The SVP also monitors and collects performance
data for key components of the storage system to enable diagnostic testing and analysis
for customer support.
The SVP provides four RJ-45 ports:
■
Two ports connect to the storage system controllers (one port for each controller).
■
One port connects to the IP network of the user.
■
One port connects to a user-supplied management console PC.
Note: This product is also designed for IT power distribution systems with
phase-to-phase voltage.
Three of the four RJ-45 ports (which connect to the controllers and the IP network) are
congured as a bridge. The SVP can be addressed using the default IP address
192.168.0.15.
In the unlikely event you cannot connect to the SVP using the default IP address, use the
following emergency login: http://<default SVP IP address>/dev/storage/
<model number><system serial number>/emergency.do. For example:
Storage system model
number
Storage system serial
number URL
8320004 456789 http://192.168.0.15/dev/
storage/8320004456789/
emergency.do
8340004 456789 http://192.168.0.15/dev/
storage/8340004456789/
emergency.do
8360004 456789 http://192.168.0.15/dev/
storage/8360004456789/
emergency.do
Users are responsible for adopting the appropriate security procedures with the SVP:
■
Applying Windows security patches.
■
Turning on automatic Windows updates or using the manual Windows update
method.
■
Installing antivirus software that has been tested and approved by Hitachi.
Service Processor
Chapter 2: Hardware components and specications
Hitachi Virtual Storage Platform G130 Hardware Reference Guide 44
