Port number
key name
(Windows
Firewall
Inbound name) Protocol
Initial value of
port number
Can the port be
closed?
SVP software
version
Automatic
allocation
88-02-0x -xx/00
or later
DeviceJettyStop HTTP 8211 N/A 88-02-0x -xx/00
or later
Automatic
allocation
88-02-0x -xx/00
or later
Hi-Track HTTPS, FTP
(SSL)
4431 Yes, only if Hi-
Track is not
used.
88-02-0x -xx/00
or later
Note: Hitachi Command Suite has additional port considerations. For more
information, refer to the Hitachi Command Suite Administrator Guide.
Controller connections
The controllers provide the ports that are required to connect to an optional SVP,
external drive trays, systems, and other devices.
A controller contains Fibre Channel ports. The number and type of ports available for
host connections vary based on the controller model.
■
Fibre Channel SFP adapters are used to connect to your Fibre Channel switch and
hosts.
Each controller also has:
■
A SAS port for connection to an external drive tray.
■
An RJ-45 10/100/1000 bps user LAN port for performing management activities.
■
An RJ-45 10/100/1000 bps maintenance LAN port for diagnostics.
Physical service processor connections
The SVP is available as an optional, physical device provided by Hitachi Vantara or as a
virtual guest host running on customer-provided ESX servers and VM/OS licenses and
media. The SVP provides error detection and reporting and supports diagnostic and
maintenance activities involving the storage system.
In a VSP G130 conguration, both the storage system and the SVP reside on the same
private network segment of your local-area network (LAN). The management console PC
used to administer the system must also reside on the same private network segment.
Controller connections
