Table 8 DBS drive tray components
Model number Part description Quantity
DW-F800-DBSC 2U chassis 1
ENC 2
AC power supply unit 2
Front bezel (2U) 1
Repeat binder (two types) 4
Omega clip 4
Bracket (L) 1
Bracket (R) 1
Side bezel (L) 1
Side bezel (R) 1
Key 2
DW-F800-RRDB Rail kit 1
Table 9 DBS optional drive tray components
Model number Part description Quantity
DKC-F810I-600JCMC 600 GB, 2.5-inch, 10kmin,
12 Gbps, SAS drive
0-24
DKC-F810I-1R2JCMC 1.2 TB, 2.5-inch, 10kmin, 12
Gbps, SAS drive
0-24
DKC-F810I-2R4JGM 2.4 TB, 2.5-inch, 10kmin, 12
Gbps, SAS, drive
0-24
Components list
Chapter 3: Parts list
Hitachi Virtual Storage Platform G130 Hardware Reference Guide 50
