1.3 LEDs
This section describes the CODA-57/57-EU’s LEDs (lights).
POWER SWITCH
(CODA-57-EU Only)
Use the switch to power on of power off your CODA-57-
EU
ON: Power on
OFF: Power off
POWER PORT Use this to connect to the 12v/2.0A power adapter that
came with your CODA-57/57-EU.
NEVER use another power adapter with your
CODA-57/57-EU. Doing so could harm your
CODA-57/57-EU.
Figure 3: Power Adaptor
Table 2: Hardware Connections
