Hitron CODA-57/57-EU User’s Guide
1.4 IP Address Setup
Before you log into the CODA-57/57-EU’s GUI, your computer’s IP address must be
in the same subnet as the CODA-57/57-EU. This allows your computer to
communicate with the CODA-57/57-EU.
If your computer is configured to get an IP address automatically, or if you are not
sure, try to log in to the CODA-57/57-EU (see
GUI Overview on page 17).
If the login screen displays, your computer is already configured correctly.
If the login screen does not display, your computer is not configured correctly.
Follow the procedure in Manual IP Address Setup on page 16 and set your
computer to get an IP address automatically. Try to log in again. If you cannot
log in, follow the manual IP address setup procedure again, and set a specific IP
address as shown. Try to log in again.
NOTE: If you still cannot see the login screen, your CODA-57/57-EU’s IP settings
may have been changed from their defaults. If you do not know the CODA-
57/57-EU’s new address, you should return it to its factory defaults. See
Resetting the CODA-57/57-EU on page 18. Bear in mind that ALL user-
configured settings are lost.
US
Green-Blinking
The CODA-57/57-EU is searching for an upstream
frequency on the CABLE connection.
Green-Steady
The CODA-57/57-EU has successfully located and
locked onto a single upstream frequency on the
CABLE connection.
Blue-Steady
The CODA-57/57-EU is successfully engaged in
channel bonding on the upstream connection.
Cyan-Steady DOCSIS 3.1
Off
There is no upstream activity on the CABLE
connection.
Online
Green-Blinking
The CODA-57/57-EU is registering with the service
provider’s CMTS.
Green-On
The CODA-57/57-EU has successfully registered
with the service provider and is ready for data
transfer (seeDOCSIS on page 19).
Off The CODA-57/57-EU’s cable modem is offline.
Table 3: LEDs
