SPECIFICATIONS
Engine Speed (rotational frequency)
at recommended max.
spindle rotational frequency 12,500/min
-1
Engine speed (rotational frequency)
at idle 3,100-4,300/min
-1
Fuel consumption (in accordance
with ISO 8893) at max.
engine performance 0.48 kg/h
Specific fuel consumption
(in accordance with ISO 8893)
at max. engine performance 0.46 kg/h
Vibration level idling
- Front Handle 4.8 m/s
2
- Rear Handle 4.8 m/s
2
Vibration level racing
- Front Handle 13.0 m/s
2
- Rear Handle 8.4 m/s
2
Sound pressure level
(in accordance with EN ISO 11806:
1997, ISO 7917:1987) 100 LpA (dBA)
Sound power level (in accordance
with ISO 10884) 113 LwA (dBpA)
DESCRIPTION
1. SILENCER GUARD 21. THROTTLE INTERLOCK
2. CHOKE LEVER 22. PRIMER BULB
3. THROTTLE CONTROL 23. RUN POSITION
AND REAR HANDLE 24. HALF CHOKE POSITION
4. STARTER GRIP 25. CHOKE POSITION
5. THROTTLE TRIGGER 26. SPOOL RETAINER
6. IGNITION SWITCH 27. SPRING
7. DRIVE SHAFT HOUSING 28. SPRING
8. FRONT HANDLE 29. SLOTS
9. GRASS DEFLECTOR 30. EYELETS
10. STRING HEAD 31. DRIVESHAFT
11. BOLT 32. ARROWS ON SPOOL
12. FLAT WASHER 33. ANCHOR HOLE
13. LOCK WASHER 34. FIRST STRING
14. WING NUT 35. SLOT
15. BRACKET 36. SECOND STRING
16. TORQUE WRENCH 37. LATCH
17. REAR HOUSING 38. PULL COVER TO OPEN
18. SCREWS 39. FILTER
19. BENT END OF 40. AIR FILTER COVER
SILENCER GUARD 41. IDLE SPEED SCREW
20. OPENING IN REAR HOUSING 42. MIXTURE NEEDLE
UNPACKING
INSTRUCTIONS
■ Carefully remove the product from the carton.
■ Inspect the product to make sure no breakage or
damage occurred during carriage.
■ Do not discard the packing material until you have
inspected and operated the product.
PACKING LIST FOR OWNER’S KIT
■ Grass deflector (9)
■ Front Handle (8)
■ Silencer guard (1), torque wrench (16) and screws (18)
■ Fixings
■ Operator’s manual
ASSEMBLY
GRASS DEFLECTOR (Fig. 2)
1. Remove wing nut (14), flat washer (12), lock washer (13),
and bolt (11) from the Owner’s Kit.
2. Place grass deflector over shaft and bracket (15).
3. Install bolt through the slots (29) in the tabs on grass
deflector and bracket on driveshaft housing (7).
4. Install flat washer, lock washer and wing nut.
5. Tighten Securely.
FRONT HANDLE (Fig. 3)
1. Remove the front handle, bolt, and wing nut from the
Owner’s Kit.
2. Install the front handle onto the top side of the drive
shaft housing and move it to a comfortable position.
3. Place the bolt through the front handle as shown, then
install the wing nut.
4. Tighten wing nut securely.
NOTE: Do not attempt to remove or modify the spacer.
This spacer limits the upper position of the handle grip.
SILENCER GUARD ASSEMBLY (Fig. 4)
1. Remove silencer guard and two screws (18) from the
owner’s kit.
2. Attach the silencer guard to the rear housing (17).
NOTE: Make sure the bent end of the silencer guard (19)
fits securely into the opening of the rear housing (20).
3. Install two screws.
4. Tighten screws securely.
