(2)
RIGHT SIDE
(2)
(1) screw
(2) right fairing pocket
(3) hooks
(3)(1)
(3)
103
Right Fairing Pocket Removal
Servicing Your Honda
Safety PrecautionsRefer to on page . Removal
The right fairing pocket must be removed
to access the coolant reserve tank.
Open the right fairing pocket cover
(page ).
Close the right fairing pocket cover.
Remove the right fairing pocket by
pulling it toward you.
Installation
Installation can be done in the reverse
order of removal.
Remove the screw (1).
Pry up on the edge of the right fairing
pocket ( ) to release the right and left
hooks ( ) as shown.
1.
2.
3.
4.
5.
82
50
2
3
