Honda 2010 FSC600 User Manual

−−
＋
−−
＋
−
1/16 1/4 in (2 6 mm)
RIGHT HANDLEBAR
(1)
(3)
(2)
()
(( ))
(1) throttle
cable boot
(2) adjuster
(3) lock nut
( ) increase
( ) decrease
125
Throttle Freeplay
Throttle
Servicing Your Honda
Safety PrecautionsRefer to on page .
Inspection
Check freeplay at the throttle grip flange.
Freeplay:
If necessary, adjust to the specified range.
Adjustment
Slide the throttle cable boot ( ) off the
adjuster ( ).
Loosen the lock nut ( ).
Tighten the lock nut and return the
throttle cable boot securely over the
adjuster.
After adjustment, check for smooth
rotation of the throttle grip from fully
closed to fully open in all steering
positions.
Turn the adjuster.
1.
2.
3.
4.
5.
1
82
2
3
０９／１２／１４ １４：５８：２４ ３１ＭＧＦ６１０ ０１３４
