LEFT SIDE
(1) side stand spring
(1)
150
Side Stand
Servicing Your Honda
Safety PrecautionsRefer to on page .
Check the side stand ignition cut-off
system:
Start the engine.
Check that the side stand assembly is
working properly. If the side stand is
stiff or squeaky, clean the pivot area
and lubricate the pivot bolt with clean
grease.
Lower the side stand all the way.
The engine should stop as you lower the
side stand. If the engine doesn’t stop,
see your Honda dealer for service.
Sit astride the scooter.
Raise the side stand.
Pull the rear brake lever in.
Check the side stand spring ( ) for
damage or loss of tension.
1.
2.
3.
4.
5.
82 1
