2.0 lb (1.0 kg)
BELOW HANDLEBAR
(1)
(3)
(1) left fairing pocket
(2) ignition key
(3) knob
(4) left fairing
pocket cover
(4)
((22))
49
Left Fairing Pocket
Cargo Compartments
Before Riding
The left fairing pocket ( ) is for
lightweight items.
Cargo in the left fairing pocket should not
exceed:
Be careful not to flood this area when
washing your scooter.
To Open the Left Fairing Pocket
Insert the ignition key (2) and turn it
clockwise.
To Close the Left Fairing Pocket
Close the left fairing pocket cover and
turn the ignition key counterclockwise.
Remove the ignition key.
Make sure the cover is closed securely.
Raise the knob ( ) by pushing it, then
open the left fairing pocket cover ( ).
1
3
4
０９／１２／１４ １４：４９：２１ ３１ＭＧＦ６１０ ００５８
