Front Top Cover
#
Removal
When removing and installing the front top
cover assembly, be careful not to damage
the wire harness.
1.
Remove the screws A.
2.
Remove the screws B.
3.
Remove the clips. 2 P. 94
4.
Disconnect the connector A and the
connector B.
5.
Remove the front top cover.
u Place the front top cover in a safety
area.
u Be careful not to damage the front top
cover and headlight lens.
#
Installation
Install the parts in the reverse order of
removal.
20230106100355_32K2FD100_eng_BOOK Page 98 Friday, January 06 2023 10:07:46 JST
Removing & Installing Body Components u Front Top Cover
Maintenance
95
Front top cover
Screws A
Clips
Screws B
Connector A
Connector B
To Next Page
