Removing & Installing Body Components
Battery
#
Removal
Make sure the ignition switch is in the
(Off) position.
1.
Remove the battery lid from the step floor
by removing the screws.
2.
Remove the battery cover by removing
the screws.
20230106100355_32K2FD100_eng_BOOK Page 95 Friday, January 06 2023 10:07:46 JST
Maintenance
92
Battery lid
Screws
Battery
cover
Screws
Negative terminal
Battery
Positive terminal
