373
Specifications
Specifications
Specif ications
■ Main Components
*1:
Including rider, passenger, all luggage, and accessories
Overall length 91.7 in (2,330 mm)
Overall width 37.8 in (960 mm)
Overall height
54.9 in (1,395 mm)
Highest position
60.8 in (1,545 mm)
Lowest position
58.7 in (1,490 mm)
Wheelbase 62.0 in (1,575 mm)
Minimum ground clearance 9.8 in (250 mm)
Caster angle 27.5°
Trail 4.4 in (113 mm)
Curb weight
505 lb (229 kg)
527 lb (239 kg)
529 lb (240 kg)
551 lb (250 kg)
Maximum weight capacity
*1
450 lb (204 kg)
Maximum weight on rear
carrier
22 lb (10 kg)
Passenger capacity Rider and 1 passenger
Minimum turning radius 8.5 ft (2.6 m)
Displacement 66.1 cu-in (1,084 cm
3
)
Bore x stroke 3.62 x 3.21 in (92.0 x 81.5 mm)
Compression ratio 10.1:1
Fuel
Unleaded gasoline
Recommended: 86 PON or higher
Tank capacity
4.97 US gal (18.8 L)
6.55 US gal (24.8 L)
To Next Page
