Refer to the Safety Precautions on page .
The service life of the drive chain is
dependent upon proper lubrication and
adjustment. Poor maintenance can cause
premature wear or damage to the drive
chain and sprockets.
The drive chain should be checked and
lubricated as part of the Pre-ride Inspection
(page ). Under severe usage, or when
the motorcycle is ridden in unusually dusty
or muddy areas, more frequent
maintenance will be necessary.
Inspection:
Turn the engine off, place the motorcycle
on its side stand and shift the
transmission into neutral.
Check slack in the lower drive chain run
midway between the sprockets.
Drive chain slack should be adjusted to
allow the following vertical movement by
hand:
Roll the motorcycle forward. Stop. Check
the drive chain slack. Repeat this
procedure several times. Drive chain
slackshouldremainconstant.Ifthechain
isslackonlyincertainsections,some
links are kinked and binding. Binding and
kinking can frequently be eliminated by
lubrication.
3.
(1)
1.
2.
82
67
(1) Drive chain
DRIVE CHAIN
97
25 35 mm (1.0 1.4 in)
30 40 mm (1.2 1.6 in)
CB400 SUPER FOUR
CB400 SUPER BOL D’OR
05/03/25 12:08:16 32MCE610_107

Honda cb400 super four Specifications

General

Displacement	399 cc
Bore x Stroke	55.0 x 42.0 mm
Compression Ratio	11.3:1
Fuel System	PGM-FI electronic fuel injection
Transmission	6-speed
Front Suspension	Telescopic fork
Fuel Tank Capacity	18 liters
Seat Height	755 mm
Final Drive	Chain
Front Tire	120/60 ZR17
Rear Tire	160/60 ZR17
Width	725 mm
Wheelbase	1, 410 mm
Ground Clearance	130 mm
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-cylinder
Max Power	53 hp (39 kW) @ 11, 000 rpm
Max Torque	39 Nm @ 9, 500 rpm
Rear Suspension	Twin shock
Front Brake	Disc brake
Rear Brake	Disc brake
Ignition	Digital transistorized
