Honda cb400 super four User Manual

Refer to the Safety Precautions on page .
Check the chain slider ( ) for wear.
The chain slider must be replaced if it is
worn to the wear limit line ( ). For
replacement, see your Honda dealer.
(1)
1
(2)
2
82
(1) Chain slider (2) Wear limit line
DRIVE CHAIN SLIDER
103
05/03/25 12:08:52 32MCE610_113

Honda cb400 super four Specifications

General

Displacement	399 cc
Bore x Stroke	55.0 x 42.0 mm
Compression Ratio	11.3:1
Fuel System	PGM-FI electronic fuel injection
Transmission	6-speed
Front Suspension	Telescopic fork
Fuel Tank Capacity	18 liters
Seat Height	755 mm
Final Drive	Chain
Front Tire	120/60 ZR17
Rear Tire	160/60 ZR17
Width	725 mm
Wheelbase	1, 410 mm
Ground Clearance	130 mm
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-cylinder
Max Power	53 hp (39 kW) @ 11, 000 rpm
Max Torque	39 Nm @ 9, 500 rpm
Rear Suspension	Twin shock
Front Brake	Disc brake
Rear Brake	Disc brake
Ignition	Digital transistorized
