Honda cb400 super four User Manual

Refer to the Safety Precautions on page .
Perform the following maintenance in
accordance with the maintenance schedule.
Functional Check:
If the side stand system does not operate as
described, see your Honda dealer for
service.
Check the side stand spring ( ) for
damage or loss of tension and the side
stand assembly for freedom of movement.
Check the side stand ignition cut-off
system:
Sit astride the motorcycle; put the side
stand up and the transmission in
neutral.
Start the engine and with the clutch
lever pulled in, shift the transmission
into gear.
Lower the side stand. The engine
should stop as you put the side stand
down.
(1)
1.
2.
3.
1
82
(1) Side stand spring
SIDE STAND
105
05/03/25 12:09:02 32MCE610_115

Honda cb400 super four Specifications

General

Displacement	399 cc
Bore x Stroke	55.0 x 42.0 mm
Compression Ratio	11.3:1
Fuel System	PGM-FI electronic fuel injection
Transmission	6-speed
Front Suspension	Telescopic fork
Fuel Tank Capacity	18 liters
Seat Height	755 mm
Final Drive	Chain
Front Tire	120/60 ZR17
Rear Tire	160/60 ZR17
Width	725 mm
Wheelbase	1, 410 mm
Ground Clearance	130 mm
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-cylinder
Max Power	53 hp (39 kW) @ 11, 000 rpm
Max Torque	39 Nm @ 9, 500 rpm
Rear Suspension	Twin shock
Front Brake	Disc brake
Rear Brake	Disc brake
Ignition	Digital transistorized
