Honda CBR300R 2018 User Manual

Removing & Installing Body Components
Battery
#
Removal
Make sure the ignition switch is in the OFF
position.
1.
Remove the front seat. 2 P. 54
2. Remove the battery holder by removing
the bolt.
3. Disconnect the negative - terminal from
the battery.
4. Disconnect the positive + terminal from
the battery.
5.
Remove the battery taking care not to
drop the terminal nuts.
#
Installation
Install the parts in the reverse order of
removal. Always connect the positive
+
terminal first. Make sure that bolts and nuts
are tight.
Make sure the clock information is correct
after the battery is reconnected. 2 P. 21
For proper handling of the battery, see
“Maintenance Fundamentals.” 2 P. 40
“Battery Goes Dead.” 2 P. 96
20170925135210_31K75A200_enu_BOOK Page 55 Monday, September 25 2017 13:58:25 JST
Maintenance
52
Positive
terminal
Battery holder
Negative
terminal
Battery
Bolt

Honda CBR300R 2018 Specifications

General

Engine Type	286cc liquid-cooled single-cylinder four-stroke
Bore and Stroke	76mm x 63mm
Compression Ratio	10.7:1
Valve Train	DOHC; four valves per cylinder
Induction	PGM-FI, 38mm throttle body
Ignition	Computer-controlled digital transistorized with electronic advance
Horsepower	30.4 HP @ 8, 500 RPM
Transmission	Six-speed
Final Drive	Chain
Front Suspension	37mm fork; 4.65 inches travel
Rear Suspension	Pro-Link single shock with five-position spring preload adjustability; 4.07 inches travel
Front Brake	Single 296mm disc with two-piston caliper
Rear Brake	Single 220mm disc
Front Tire	110/70-17
Rear Tire	140/70-17
Rake	25.3°
Trail	98mm (3.9 inches)
Wheelbase	54.3 inches
Seat Height	30.7 inches
Fuel Capacity	3.4 gallons
MPG	71 MPG
Fuel System	PGM-FI
Curb Weight	357 pounds
