Honda CBR300R 2018 User Manual

Harness Band Clip
#
Removal
Pull the harness band clip while pressing
both side of the anchor.
#
Installation
Install the harness band clip until it seats
properly.
Middle Cowl
The right and left middle cowl removal can
be done in the same way.
#
Removal
1. Remove the clips. 2 P. 53
2.
Remove the bolts A, bolts B and bolt C.
20170925135210_31K75A200_enu_BOOK Page 58 Monday, September 25 2017 13:58:25 JST
Removing & Installing Body Components u Harness Band Clip
Maintenance
55
Continued
Anchor
Bolt A
Bolt C
Middle
cowl
Bolt B
ClipBolt A
Clip
Bolt B

Honda CBR300R 2018 Specifications

General

Engine Type	286cc liquid-cooled single-cylinder four-stroke
Bore and Stroke	76mm x 63mm
Compression Ratio	10.7:1
Valve Train	DOHC; four valves per cylinder
Induction	PGM-FI, 38mm throttle body
Ignition	Computer-controlled digital transistorized with electronic advance
Horsepower	30.4 HP @ 8, 500 RPM
Transmission	Six-speed
Final Drive	Chain
Front Suspension	37mm fork; 4.65 inches travel
Rear Suspension	Pro-Link single shock with five-position spring preload adjustability; 4.07 inches travel
Front Brake	Single 296mm disc with two-piston caliper
Rear Brake	Single 220mm disc
Front Tire	110/70-17
Rear Tire	140/70-17
Rake	25.3°
Trail	98mm (3.9 inches)
Wheelbase	54.3 inches
Seat Height	30.7 inches
Fuel Capacity	3.4 gallons
MPG	71 MPG
Fuel System	PGM-FI
Curb Weight	357 pounds
