Honda CRF250X User Manual

50 Servicing Your Honda
Coolant Replacement
Refer to Safety Precautions on page 25.
Coolant should be replaced by your Honda
dealer, unless you have the proper tools and
service data and are mechanically qualified.
Refer to the Honda Shop Manual.
Coolant
WARNING
Removing the radiator cap while the
engine is hot can cause the coolant to
spray out, seriously scalding you.
Always let the engine and radiator cool
down before removing the radiator cap.
To properly dispose of drained coolant, refer to
You & the Environment, page 143.
Improper disposal of drained fluids is harmful to
the environment.
NOTICE
Coolant System Bleed Air
1. Remove the radiator cap (1).
(1) radiator cap
2. Fill the system with the recommended coolant
through the filler opening up to filler neck.
Use a fresh recommended coolant mixture
(page 48).
Capacity:
1.20R(1.27 US qt, 1.06 Imp qt) after
disassembly
1.13R(1.19 US qt, 0.99 Imp qt) after
coolant change
3. Turn the quick fastener (2) counterclockwise
and open the air cleaner housing cover (3).
4. Remove the left side cover bolt (4), collar (5),
seat mounting bolt (6) and left side cover (7).
5. Remove the reserve tank cap (8) and fill the
reserve tank to the UPPER level line (9).
(2) quick fastener (6) seat mounting bolt
(3) air cleaner housing cover (7) left side cover
(4) left side cover bolt (8) reserve tank cap
(5) collar (9) UPPER level line
6. Bleed air front the system as follows:
• Shift the transmission into neutral. Start the
engine and let it idle 2 – 3 minutes.
• Snap the throttle three-four times to bleed air
from the system.
• Stop the engine and, if necessary, add
coolant up to the proper level. Reinstall the
radiator cap.
• Check the level of coolant in the reserve
tank and fill to the UPPER level if it is low.
If the radiator cap is not installed properly, it
will cause excessive coolant loss and may result
in overheating and engine damage.
7. Install the radiator reserve tank cap and left
side cover, and close the air cleaner housing
cover.
NOTICE
(1)
(9)
(8)
(6)
(7)
(4)
(3)
(5)
(2)
250X_030-059.qxd 08.7.3 10:10 ページ50

Honda CRF250X Specifications

General

Engine Type	249cc liquid-cooled single-cylinder four-stroke
Bore and Stroke	78.0mm x 52.2mm
Compression Ratio	12.9:1
Induction	Keihin 37mm flat-slide carburetor
Ignition	CDI
Transmission	Wide-ratio five-speed
Front Suspension	47mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability; 12.4 inches travel
Front Brake	Single 240mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	100/100-18
Trail	113mm (4.4 inches)
Wheelbase	58.3 inches
Seat Height	37.7 inches
Fuel Capacity	1.9 gallons
Final Drive	520 chain; 13T/51T
Rake	27.5 degrees
Rear Suspension	Pro-Link Showa single shock with spring preload, 17-position rebound damping adjustability, and 13-position compression damping adjustability; 12.4 inches travel
Curb Weight	254 lbs (Includes all standard equipment, required fluids and a full tank of fuel—ready to ride)
