Honda CRF450X 2017 User Manual

36 Servicing Your Honda
Seat
Refer to Safety Precautions on page 25.
Removal
1. Remove the seat mounting bolts (1).
2. Remove the seat (2) by sliding it backward.
(1)
(2)
(1) seat mounting bolts
(2) seat
Installation
1. Install the seat (1) while aligning the seat
front prong (2) with the seat bracket (3) and
seat rear prongs (4) with the tabs (5) of the
frame.
2. Install and tighten the seat mounting bolts (6)
to the specified torque.
19 lbf·ft (26 N·m, 2.7 kgf·m)
(2)
(4)
(1)
(6)
(3)
(5)
(1) seat
(2) seat front prong
(3) seat bracket
(4) seat rear prongs
(5) tabs
(6) seat mounting bolts
