Honda CRF450X 2017 User Manual

62 Servicing Your Honda
Exhaust Pipe/Muffler
Exhaust Pipe/Muffler Inspection
Check the mounting bolts and exhaust pipe joint
nuts for tightness.
Check the exhaust pipe and muffler for cracks or
deformation.
A damaged exhaust pipe and muffler may reduce
engine performance.
2. Loosen the muffler clamp bolt (4).
3. Remove the rear muffler mounting bolt/
washer (5), front muffler mounting bolt (6)
and muffler (7).
(4)
(7)
(6)
(5)
(4) muffler clamp bolt
(5) rear muffler mounting bolt/washer
(6) front muffler mounting bolt
(7) muffler
Muffler Removal
1. Remove the seat mounting bolt (1), side
cover bolt (2) and right side cover (3).
(1)
(3)
(2)
(1) seat mounting bolt
(2) side cover bolt
(3) right side cover
17CRF450X31MEY710.indb6217CRF450X31MEY710.indb62 2016/06/0811:45:472016/06/0811:45:47
