TECHNICAL INFORMATION
82
SPECIFICATIONS
Dimensions
Engine
Generator
Model (Type) EU3000is1
Description code EZGF
Length 25.9 in (658 mm)
Width 17.6 in (447 mm)
Height 22.0 in (558 mm)
Dry mass [weight] 130.7 lbs (59.3 kg)
Model GX200T2
Engine type 4-stroke, overhead valve, single cylinder
Displacement
[Bore × Stroke]
12.0 cu-in (196 cm
3
)
[2.68 × 2.13 in (68.0 × 54.0 mm)]
Compression ratio 8.5:1
Engine speed 3,500–3,800 rpm
(with Eco-Throttle switch OFF)
Cooling system Forced air
Ignition system Transistor magneto
Oil capacity 18 oz (0.55 L)
Fuel tank capacity 3.43 US gal (13.0 L)
Spark plug BPR6ES (NGK) · W20EPR-U (DENSO)
Model EU3000is1
Type AG type
AC output Rated voltage 120 V
Rated frequency 60 Hz
Rated current 23.3 A
Rated output 2.8 kVA
Maximum output 3.0 kVA
