2013.04.10 E
F-14
73
FLOOR STEP
3
19 93903-34380 SCREW, TAPPING, 4X12 •••••••• 6 6
20 93903-34480 SCREW, TAPPING, 4X16 •••••••• 18 18
21 93903-35380 SCREW, TAPPING, 5X16 •••••••• 1 1
Ref.
No.
Part No. Description
Reqd. QTY
Parts catalogue code
NSS NSS
300 300A
D D
Serial No.
G 8
http://www.motorcycle.in.th

Table of Contents

Other manuals for Honda NSS300

Preview: Owner's Manual
Owner's Manual119 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda NSS300 and is the answer not in the manual?

Honda NSS300 Specifications

General IconGeneral
Displacement279cc
Bore x Stroke72mm x 68.5mm
Compression Ratio10.5:1
Fuel SystemPGM-FI electronic fuel injection
TransmissionAutomatic V-Matic belt drive
Rear BrakeSingle 240mm disc with single-piston caliper
Front Tire120/70-14
Rear Tire140/70-13
IgnitionFull transistorized ignition
StarterElectric
Engine TypeLiquid-cooled single-cylinder four-stroke
Front Suspension33mm hydraulic telescopic fork
Rear SuspensionTwin shock
Front BrakeSingle 256mm disc with 3-piston caliper
Fuel Capacity3.3 gallons
