Specifications
Frame
Engine
Engine
Specifications may vary according to the types, and are subject to change
without notice.
MODEL UMC425 UMC435
Description code HAGT HALT HAHT HAMT
Type LAAT
LAC1, LAC2 LAAT LAC1, LAC2
MODEL UMC425 UMC435
Handle type Loop
Clutch type Centrifugal clutch
Overall length 44.7 in (1,135 mm) 45.1 in (1,145 mm)
Overall width 12.4 in (315 mm) 12.6 in (320 mm)
Overall height 9.6 in (245 mm) 10.0 in (255 mm)
Dry mass (weight) 11.2 lbs (5.1 kg) 13.2 lbs (6.0 kg)
MODEL UMC425
Engine model GX25T
Engine description code GCALT
Engine type 4-stroke, overhead cam, single cylinder
Displacement
1.5 cu-in (25.0 cm
3
)
Bore x Stroke 1.4 × 1.0 in (35.0 × 26.0 mm)
Idle speed 3,100 ± 200 rpm
Maximum no load engine
speed
MIN. 10,000 rpm
Cooling system Forced air
Ignition system Transistor magneto
Engine oil capacity 2.7 oz (0.08 L, 2.82 fl Imp oz)
Fuel tank capacity 0.14 US gal (0.53 L, 18.7 fl Imp oz)
Spark plug CMR5H (NGK)
MODEL UMC435
Engine model GX35T
Engine description code GCAMT
Engine type 4-stroke, overhead cam, single cylinder
Displacement
2.18 cu-in (35.8 cm
3
)
Bore x Stroke 1.5 × 1.2 in (39.0 × 30.0 mm)
Idle speed 3,100 ± 200 rpm
Maximum no load engine
speed
MIN. 10,000 rpm
Cooling system Forced air
Ignition system Transistor magneto
Engine oil capacity 3.3 oz (0.10 L, 3.52 fl Imp oz)
Fuel tank capacity 0.17 US gal (0.63 L, 22.2 fl Imp oz)
Spark plug CMR5H (NGK)
Tuneup Specifications
Quick Reference Information
ITEM SPECIFICATION MAINTENANCE
Spark plug gap 0.024–0.028 in
(0.6–0.7 mm)
Refer to page: 17
Idle speed 3,100±200 rpm See your servicing
dealer
Valve clearance
(cold)
IN: 0.08±0.02 mm
EX: 0.11±0.02 mm
Other
specifications
No other adjustments needed.
Fuel Regular unleaded gasoline with an ethanol content
of no more than 10% and a pump octane rating of
86 or higher (see page 14).
Engine oil SAE 10W-30, API SJ or later, for general use.
Include capacities:
UMC425: 2.7 oz (0.08 L, 2.82 fl Imp oz)
UMC435: 3.3 oz (0.10 L, 3.52 fl Imp oz)
Refer to page 14.
Spark plug CMR5H (NGK)
Maintenance Before each use:
• Check engine oil level. Refer to page 14.
• Check air filter. Refer to page 16.
First 10 hours:
Change engine oil. Refer to page 15.
Subsequent:
Refer to the maintenance schedule on page 13.
