Honda Wave 110i User Manual

Tyre Puncture u Removing Wheels
85
Troubleshooting
Installation
1. To install the rear wheel, reverse the
removal procedure.
2. Tighten the rear axle nut.
3. Tighten the stopper arm nut.
4. Adjust the rear brake pedal freeplay.
2 P. 72
5. Adjust the drive chain slack. 2 P. 66
6. After installing the wheel, apply the brake
several times and then check if the wheel
rotates freely. Recheck the wheel if the
brake drags or if the wheel does not
rotate freely.
If a torque wrench was not used for
installation, see your dealer as soon as
possible to verify proper assembly.
Improper assembly may lead to loss of
braking capacity.
A used cotter pin may not effectively secure a
fastener. Always replace a used cotter pin
with a new one.
Torque: 59 N·m (6.0 kgf·m, 44 lbf·ft)
Torque: 22 N·m (2.2 kgf·m, 16 lbf·ft)
12 AFS110-32KWWH00.book 85 ページ ２０１１年１０月２６日 水曜日 午後５時２２分
http://www.motorcycle.in.th

Honda Wave 110i Specifications

General

Displacement	109.5 cc
Bore x Stroke	50.0 mm x 55.6 mm
Compression Ratio	9.0:1
Fuel System	PGM-FI (Programmed Fuel Injection)
Transmission	4-speed
Starter	Electric and kick
Final Drive	Chain
Front Suspension	Telescopic fork
Rear Brake	Drum
Front Tire	70/90-17M/C 38P
Rear Tire	80/90-17M/C 50P
Ground Clearance	135 mm
Engine Type	4-stroke
Rear Suspension	Twin shock
Front Brake	Disc
Ignition System	Full Transistorized
