Drive Chain
Inspecting the Drive Chain
Slack
Check the drive chain slack at several points
along the chain. If the slack is not constant at
all points, some links may be kinked and
binding.
Have the chain inspected by your dealer.
1.
Place your motorcycle on the centre
stand on a level surface.
2.
Stop the engine place the gear in
Neutral.
3.
Check the slack in the lower half of the
drive chain midway between the
sprockets. Move the drive chain up and
down with your finger.
u Do not ride your motorcycle if the
slack exceeds 50 mm (2.0 in).
4.
Rotate the rear wheel and check that the
chain moves smoothly.
5.
Inspect the sprockets. 2 P. 45
6.
Clean and lubricate the drive chain.
2 P. 46
Drive chain slack:
20 to 30 mm (0.8 to 1.2 in)
