Environmental Specifications
The operating conditions are as follows:
n Storage temperature: -40°C to +85°C (–40°F to +185°F)
n Operational Ambient temperature (T4): -40°C to +70°C (-40°F to
+158°F)
n Relative humidity: 5% to 95% (non-condensing)
n Vibration (sinusoidal): excitation: sine-shaped with sliding freq.
o
frequency range: 10 ~ 2000 Hz
o
loads: 10 ~ 150 HZ 1.0g
o
150 Hz ~ 2000 Hz: 0.5g
o
no. of axes: 3 (x, y, z)
o
traverse rate: 1 oct/min.
n Shock: 4g max. / 25ms 6 direction
Power Considerations
Power Requirements
Power is supplied to the controller and NAM through the power input
terminals on the controller IOTA. The relevant specifications at each
power input terminals are detailed in the following table.
Model
Number
Rated input
voltage
Input voltage
range
Maximum ripple
voltage
Maximum rated input
current
CC-
IION01
24 VDC 18 to 30 VDC 120 mVpp 0.13 A at 30 VDC
NAM 24 VDC 18 to 30 VDC 120 mVpp 0.05 A at 30 VDC
Table 4-1: Power Requirements
ATTENTION: To comply with CE certification, use shielded wire
to connect to the 24 VDC power source. Not to be connected to
DC distribution network only via CE Certified power supply.
18
Chapter 4 - CN100 Platform Installation
