Wire Type Power input RS485 Connector

Solid Wire (MAX) 12 AWG 12 AWG

Stranded Wire (MAX) 14 AWG 14 AWG

With plastic collar ferrule (MAX) 1.5 mm² 1.5 mm²

Table 4-5: Wire Conductor Size Range for Ports and Connectors

Communication Cabling

Ethernet cables

Ethernet cables are used in Series C cabinets to interconnect Control

Firewall IOTAs, CN100 Controller IOTAs, and Series C Modules. Only

shielded twisted pair (STP) type cable is used. The use of unshielded

twisted pair (UTP) cable is not allowed.

Other in-cabinet Ethernet cable parts

One of the following yellow-colored (FTEA) cables and one of the

following green-colored (FTEB) Ethernet cables are used to connect a

Control Firewall IOTA to a CN100 Controller IOTA or to a Series C

Modules.

Description Model or

Part

Number

FTE Link A Cables
