Power Consumption
This sections describes the power consumption details of the CN100
NAM. The following table only includes power consumption data of
the listed modules and does not include power consumption of any
connected instruments.
Power Consumption Under Ethernet
connection
Power Consumption under fiber
connection
10 W 12 W
Note 1 – Input voltage 24 Vdc; Two Controllers; Two NAM with
Ethernet port active.
Note 2 – Input voltage 24 Vdc; Two Controllers; Two NAM with fiber
port active.
Table 4-2: Power Consumption, Redundant Controller
Installation Declarations
ATTENTION: This equipment shall be installed in accordance
with the requirements of the National Electrical Code (NEC),
ANSI/NFPA 70, the Canadian Electrical Code (CEC) or
EN/IEC60079-14 and applicable National regulations in
Europe. See "Special Condition of Use for Division 2/Zone 2
Hazardous Location Installation" on page52 for more
information. The suitability of the enclosure and installed
system shall be acceptable to the local "authority having
jurisdiction," as defined in the NEC, or "authorized person" as
defined in the CEC. Where installed in outdoor or potentially
wet locations, the enclosure shall, at a minimum, meet the
requirements of IP54 in accordance with CAN/CSA 60529.
Chapter 4 - CN100 Platform Installation
To Next Page
