Honeywell DVC100 (M) MK2 User Manual

CERTIFICATION (Cont)
System Connections
SYSTEM 1
SENSOR/DETECTOR OR
REMOTE SENSOR/DETECTOR
CONNECTED VIA SUITABLE Ex e
OR Ex d GLANDS
EARTH
+24V
0V
A
B
4-20mA
TRANSMITTER/SENSOR
CONNECTED VIA SUITABLE Ex e
OR Ex d CABLE GLANDS
EARTH
+24V
0V
TERMINATION UNIT
DVC 100 (M) MK2
COMMUNICATION
LINK SOCKET
A B 0V
VOLTAGE
CLAMP
B A 0V +24V
A B IS0 BE1 BE1
1 2 3 4 5 6 7 8 9
10 11 12
FIELD WIRING
SUPPLY
+24V 0V 4-20mA EARTH
HAZARDOUS AREA SAFE AREA
TRANSMITTER/SENSOR ENTRY
OPTIONAL
TRANSMITTER/
SENSOR
ANY SUITABLE ATEX APPROVED SENSOR/DETECTOR
SENSOR ENTRY
SENSOR/
DETECTOR
ANY SUITABLE ATEX APPROVED SENSOR/DETECTOR
SUPPLY ENTRY
OPTIONAL
TERMINATION UNIT
DVC100 (M)
Baseefa
03ATEX0287
HANDHELD
CALIBRATOR
TYPE SHC 1
Baseefa
03ATEX0073
COMMUNICATIONS SOCKET I.S OUTPUT TO CALIBRATOR (FACTORY FIXED)
SYSTEM 2
B A 0V +24V
VOLTAGE
CLAMP
A B IS0 BE1 BE1
1 2 3 4 5 6 7 8 9
10 11 12
SENSOR/DETECTOR OR
REMOTE SENSOR/DETECTOR
CONNECTED VIA SUITABLE Ex e
OR Ex d GLANDS
EARTH
A
B
4-20mA
TERMINATION UNIT
DVC 100 (M) MK2
OPTIONAL
EARTH LINK ‘A’
CONTINUITY
PLATE
EARTH
EARTH LINK ‘B’ ALTERNATIVE
TO EARTH LINK ‘A’
CONTINUITY
PLATE
COMMUNICATION
LINK SOCKET
A B 0V
20
