Honeywell ERM5220R User Manual

3 33-00135EFS—07
Lista de verificación para la instalación
MATERIALES PROPORCIONADOS:
• ERM5220R
• Tarugos de pared (2) y tornillos de montaje (2)
• Tornillo para cubierta adicional (opcional)
• Instrucciones de instalación
HERRAMIENTAS NECESARIAS (NO SE SUMINISTRAN):
•Taladro
• Accesorio de inserción de tuercas para uso con el taladro
• Pelacables
• Destornillador pequeño de hoja plana
• Destornillador de estrella
• Transformador de 120/240 V a 24 V (opcional)
M35671
INSTALL GUIDE
33-00135EFS-03
ERM5220R
Equipment Remote Module
WITH REDLINK™ WIRELESS TECHNOLOGY
Table of Contents
About the ERM5220R 2
Installation Checklist 3
Terminal Designations 4
Installation 6
Checkout 12
Troubleshooting 14
Specifications 16
5 Year Warranty 18
CAUTION
Read these installation instructions completely and follow them
carefully.
Installation must be performed by a qualified service technician and
must comply with local codes.
Disconnect power to all relevant devices before installing or
servicing the ERM.
Failure to connect the device according to these instructions may
result in damage to the device, the controls, and/or personal injury.
M35669
M35672
M35670
