Honeywell F50F Manual

11 68-0137B—2
F50F
INSTALLATION
Fig. 14—Internal schematic for electronic air cleaner with W8600E.
P3
P4
P1
P2
P17
P18
2
1
P14
P5
P12
3
P21
4
BLACK
1
2
3
4
1
2
3
4
TERMINAL STRIP
FRONT BACK
TO
W8600E
WALL
PANEL
W4 W2 W1 W3
AIR FLOW SWITCH BOARD
ORANGE
GRAY
VIOLET
BLACK
1 INTERLOCK SWITCH.
2 OUTPUT REDUCTION JUMPER.
3 AIRFLOW SWITCH DISABLE JUMPER.
4 RESISTOR FOR W8600 WASH INDICATION THRESHOLD.
5 ONE-CELL UNIT SIMILAR, BUT WITH JUST ONE CELL.
6 P1, P2 TERMINALS ON 120V MODELS ONLY. POWER CONNECTIONS ON 240V MODELS ARE TO QUICK-CONNECTS ON POWER
SUPPLY TRANSFORMER. BROWN LEAD GOES TO TOP TERMINAL AND BLACK LEAD TO BOTTOM TERMINAL.
M6157A
POWER
SUPPLY
2
5
BLACK
RED
TEST
BUTTON
CONTACT
BOARD
RED IONIZER
BLACK COLLECTOR
BLACK
J2
6
4
R43
BLACK
BLACK
BROWN
BLACK
BLACK
WHITE
GREEN
3
1
GREEN
J7
Fig. 15—Removing cover from power box.
1
2
M5676
3
