19 68-0137B—2
F50F
REPLACEMENT PARTS/EXPLODED VIEW
Replacement Parts/Exploded View
Nominal Return Air Opening
16 x 25 in. 20 x 25 in. 20 x 12-1/2 in. 20 x 20 in.
No. Description [406 x 635 mm] [508 x 635 mm] [508 x 318 mm] [508 x 508 mm]
1 Access Door includes #2 203306AB (1) 203305AB (1) 203305AB (1) 203305AB (1)
2 Test Button Assembly 137980A (1) 137980A (1) 137980A (1) 137980 (1)
3 Electronic Cell FC37A1130 (2) FC37A1064 (2) FC37A1064 (1) FC37A1049 (2)
4 Cell Handle 137266 (2) 137266 (2) 137266 (1) 137266 (1)
5 Prefilter 136388 (2) 136389 (2) 136389 (1) 199664 (2)
6 Cell Key 136518 (1) 136518 (1) 136518 (1) 136518 (1)
7 Power Box Assembly 203314B (1) 203314A (1) 203316A (1) 203315A (1)
Includes #8 - #20, 120V, 60 Hz
240V, 60 Hz N/A N/A 203316B (1) N/A
8 Switch 203321 (1) 203321 (1) 203321 (1) 203321 (1)
9 Power Box Cover and Label 203318A (1) 203318A (1) 203320A (1) 203319A (1)
10 Power Supply, 120V, 60 Hz 203101B (1) 203101A (1) 203101C (1) 203101B (1)
240V, 60 Hz N/A N/A 203454C (1) N/A
11 Interlock Bracket and Switch 4074ETG (1) 4074ETG (1) 4074ETG (1) 4074ETG (1)
12 W8600 Terminal Strip 200546C (1) 200546C (1) 200546B (1) 200546C (1)
13 Terminal Board Assembly Front 203329B (1) 203329B (1) 203329D (1) 203329C (1)
14 Terminal Board Assembly Rear 203329A (1) 203329A (1) N/A 203329A (1)
15 Barrier Plate 203331 (1) 203331 (1) 203331 (1) 203331 (1)
16 Strain Relief 203852 (1) 203852 (1) 203852 (1) 203852 (1)
17 Line Cord 4074ETD (1) 4074ETD (1) 4074ETD (1) 4074ETD (1)
18 Hole Plug 203847 (1) 203847 (1) 203847 (1) 203847 (1)
19 Neon Assembly 4074ETE (1) 4074ETE (1) 4074ETE (1) 4074ETE (1)
20 Airflow Switch 4074ETH (1) 4074ETH (1) 4074ETH (1) 4074ETH (1)
21 FC37A Bag Assembly for cell repair 4074EHG (1) 4074EHG (1) 4074EHG (1) 4074EHG (1)
contains two Connector Clips, one
Terminal Board and Instructions
(#) = Quantity required per unit. N/A = Not available as merchandised part.
Parts and Accessories not Illustrated
Nominal Return Air Opening
16 x 25 in. 20 x 25 in. 20 x 12-1/2 in. 20 x 20 in.
Description [406 x 635 mm] [508 x 635 mm] [508 x 318 mm] [508 x 508 mm]
Ionizer Wires (multiples of five) 136434BA 136434AA 136434AA 136434AA
Mounting Screws 136375 (6) 136375 (6) 136375 (6) 136375 (6)
2-Stage EAC Cell for F50 FC37A1247 (2) FC37A1239 (2) FC37A1239 (2) N/A
with Collector Clip
(#) = Quantity required per unit. N/A = Not available as merchanised part.
