4.7.3 Detector Markings
Class I, Division 1, Groups A, B, C & D; Class II, Division 1 Groups E, F & G; Class III; Class I, Zone 1 AEx d /Ex d
IIC Hazardous Locations.
ATEX IECEx CertificationClass I, Zone 1, Ex db IIC (T4-T6) and Ex tb IIIC (T4-T6).
ATEX Certification FM14ATEX0058X
IECEx Certification FMG 14.0027X
Ex db IIC T6….T4 Gb
Ex tb IIIC T135C Db IP66
II 2 G Ex db IIC T6…T4 Gb
II 2 Ex tb IIIC T135C IP66
LABEL CONFIGURATIONS
P/N
Model
No.
Full Description Material IR/UV
Type
LPCB Number
CPR Number
Background
color
Text
Color
mA T4 T5: T6:
LB-
6095-
001
FS20X
Label, FS20X, ss, with
FM/Canada/US ATEX,
IECEX approval
0.020” 316
Stainless
Steel
WideBand
IRTM/UV
1175a/01
0832-CPR-F0515
Matte
Black
150
-40ºC
to
+110ºC
-40ºC
to
+75ºC
-40ºC
to
+60ºC
LB-
6095-
003
FS24X-9
Label, FS24X-9, ss, with
FM/Canada/US ATEX,
IECEX approval
0.020” 316
Stainless
Steel
QuadBand
Triple
IRTM
1175a/02
0832-CPR-F0516
Matte
Black
150
-60ºC
to
+110ºC
-60ºC
to
+75ºC
-60ºC
to
+60ºC
Part
Number
Model
Number
Material
Background
Color
Text Color mA T4 T5 T6
LB-6093-
041
FS19X 0.020' Al 1100-Hl4 Black White 150 -40C to +110C
-40C to
+75C
-40C to
+60C
LB-6093-
042
FS19X
0.020' 316
Stainless Steel
Polished Black 150 -40C to +110C
-40C to
+75C
-40C to
+60C
LB-6093-
043
FS19X 0.020' Al 1100-Hl4 Black White 150 -40C to +110C
-40C to
+75C
-40C to
+60C
LB-6093-
044
FS19X
0.020' 316
Stainless Steel
Polished Black 150 -40C to +110C
-40C to
+75C
-40C to
+60C
LB-6093-
037
FS20X 0.020' Al 1100-Hl4 Black White 150 -40C to +110C
-40C to
+75C
-40C to
+60C
LB-6093-
038
FS20X
0.020' 316
Stainless Steel
Polished Black 150 -40C to +110C
-40C to
+75C
-40C to
+60C
LB-6093-
039
FS20X 0.020' Al 1100-Hl4 Black White 150 -40C to +110C
-40C to
+75C
-40C to
+60C
LB-6093-
040
FS20X
0.020' 316
Stainless Steel
Polished Black 150 -40C to +110C
-40C to
+75C
-40C to
+60C
To Next Page
