Mechanics of Programming
*HQHUDO3URJUDPPLQJ,QIRUPDWLRQ
Programming options are stored in non-removable, electrically erasable, nonvolatile EEROM
memory. The system can be programmed at any time, even at the installer's premises prior to the
actual installation. Simply apply power temporarily to the Control and then program the unit as
desired. There are two programming modes:
•
Data field programming
(used for setting various system options)
•
Interactive menu mode programming
(used for programming zone information, programming Powerline
Carrier Devices, and for entering transmitter serial numbers)
The system can also be programmed remotely, using an IBM Personal Computer, a modem, and Compass
Downloader for Windows. See the
Remote Programming/Control (Downloading)
section
.
1RWH <RX PD\ ILQG LW FRQYHQLHQW WR DGMXVW WKH YROXPH VHWWLQJ EHIRUH HQWHULQJ WKH 3URJUDP 0RGH 7KLV ZLOO DOORZ \RX WR FOHDUO\
KHDU WKH IHHGEDFN DQQRXQFHPHQWV RU V\VWHP EHHSV LQ WKH 3URJUDPPLQJ 0RGH RI WKH V\VWHP·V EXLOWLQ VSHDNHU 7R DGMXVW
WKH YROXPH SUHVV )81&7,21  92/80( >@ RU >@ 8SRQ H[LWLQJ WKH 3URJUDP 0RGH WKH V\VWHP ZLOO UHVHW WKH YROXPH WR
WKH GHIDXOW YDOXH PLG OHYHO


&HUWDLQ IHDWXUHV GLIIHU EHWZHHQ WKH /<1;5/<1;5 DQG WKH /<1;5(1 PRGHOV 9HULI\ WKH VSHFLILF PRGHO EHLQJ
LQVWDOOHG SULRU WR WKH V\VWHP SURJUDPPLQJ
Entering Program Mode -
Use one of the following methods to enter Programming Mode:
1. Press both the [
✳
] and [#] keys at the same time,
within 50 seconds
after power is applied to the Control or
from exiting Programming mode,
OR
2. After power-up, enter the
Installer Code (4112) + 800
(This method disabled if Program mode is exited
using
✳
98.) to enter
Expert Programming
mode or
Installer Code (4112) + 888 to enter Voice Prompt
Programming
mode.
1RWH ,I D GLIIHUHQW ,QVWDOOHU &RGH KDV EHHQ SURJUDPPHG XVH WKDW FRGH WR HQWHU WKH 3URJUDPPLQJ PRGH 2QFH \RX KDYH HQWHUHG
WKH 3URJUDP PRGH GDWD ILHOG
✻
 WKH ILUVW GDWD ILHOG LQ WKH V\VWHP ZLOO EH GLVSOD\HG DQG ERWK NH\SDG /('V ZLOO IODVK
Programming a Data Field
1. Press [
✳
] + Field No. (for example,
✳
21), followed by the required entry.
2. When you have completely programmed a data field, the keypad will “beep” three times and then
automatically display the next data field in sequence. To go to a different field, press [
✳
] plus the desired
field number.
3. If the number of digits that will be entered in a data field is less than the maximum number of digits
available (e.g. phone number field), enter the desired data, then press [
✳
] to advance to the next data field.
4. If a nonexistent field has been entered, the keypad will display “EE”. Simply re-enter [
✳
] plus a valid field
number.
To view a data field
without making changes: Enter [#] +
Field No.
Data will be displayed for that field.
To delete an entry
in a field: Enter [
✳
]
+
Field No.
+
[
✳
]. (Applies only to fields
✻
40–
✻
44,
✻
88 and
✻
94).
Interactive Mode Programming (
✻56, ✻80, ✻81, ✻83, ✻84, ✻85)
Press
[
✳
]
+
interactive mode No.
(for example,
✻
56). The keypad will display the first of a series of prompts.
A detailed procedure (with displays of prompts) is provided in later sections of this manual.
Interactive Mode Used to Program
✻
56 Enhanced Zone Programming Mode
Zone characteristics, report codes, and serial numbers
✻
80 Device Programming Menu Mode
Powerline Carrier Devices
✻
81 Zone List Menu Mode
Zone Lists for powerline carrier activation
✻
83 Enhanced Sequential Mode
5800 Series transmitter serial numbers
✻
84 Assign Zone Voice Descriptors
Voice descriptors for each zone
✻
85 Record Custom Voice Descriptors
Up to 5 custom voice descriptors for zones
Loading Factory Defaults
To load the factory defaults, enter the Programming mode, press
✻
97, then press number 1, 2, 3, or 4 to select
from default tables 1-4 at the back of this manual, or press “0” if you are not selecting a default table.

,I D GHIDXOW WDEOH LV ORDGHG DQ\ GDWD WKDW KDV DOUHDG\ EHHQ SURJUDPPHG LQWR WKH V\VWHP ZLOO EH FKDQJHG DFFRUGLQJ WR
WKH GHIDXOW WDEOH VHOHFWHG
✻96
resets all subscriber account numbers and CSID in preparation for an initial download.
Exiting Program Mode
✻98
inhibits re-entry into the Expert or Voice Prompt Programming modes using the Installer Code.
✻99
allows re-entry into the Expert Program mode using
Installer Code (4112) + 800
or into the
Voice
Prompt Programming
mode using
Installer Code (4112) + 888
.
1RWH $IWHU H[LWLQJ SURJUDP PRGH RU XSRQ SRZHUXS WKH V\VWHP WDNHV XS WR D PLQXWH WR UHVHW 7R E\SDVV WKH UHVHW GHOD\ SUHVV
[#] + [0].
