Chapter 4 — Printer Configuration
MP Compact4 Mark III User Guide 15
Control Button
The control button performs different functions depending upon the mode of the
printer.
Configuration Label
Initiation of this mode causes the printer to print its configuration label and to
begin the hex dump mode.
The configuration label provides valuable printer information including the
firmware version, memory allocations, enabled options, communications
settings, and label-counter data. To print a configuration label:
1 Be sure the printer is properly loaded with media (at least four inches wide),
and that the power to the printer is off.
2 Turn on the printer.
3 When the status light turns on, press and hold the control button until
printing begins.
After the printer has completed printing the configuration label, the printer will
enter hex dump mode. In this mode, all data sent to the printer will be
immediately output in hexadecimal code, along with the printable ASCII
equivalents. The hex dump mode is a useful tool for advanced users in the
diagnosis of problems including communications, handshaking, and label
format syntax errors. To decode this information, the Programmer’s Manual is
an essential reference.
To exit hex dump mode simply turn the printer off or perform a “Printer Reset”
by holding the control button for at least 25 seconds.
Using the Control Button
Button Action
Ready
(LED – Green)
Busy/Printing
(LED – Green Flashing)
Paused
(LED – Orange)
Faulted
(LED – Red)
Momentary Press Feeds label Pauses printer Resumes printing Clears fault
Press and hold for 5
seconds (release when
LED blinks orange)
Prints network
report
Cancels batch
Press and hold for 10
seconds (release when
LED blinks green)
Performs the quick media calibration
Press and hold for 15
seconds (release when
LED blinks red)
Resets the printer’s parameters to the stored dealer settings. Resetting the printer will clear
the RAM of downloaded images, fonts and label formats, and remove temporary printer
configuration changes.
Press and hold for 20
seconds (release when
LED blinks orange)
Resets parameters to factory defaults
Press and hold for 25
seconds
Resets the printer
