Chapter 5 — Printer Maintenance
MP Compact4 Mark III User Guide 29
Replace Printhead
To remove
1 Turn the printer off and unplug the printer. Unlock the printhead latch and
remove any media installed in the printer.
2 Lower the front panel (item 1). Allow the printhead to cool before
proceeding.
3 Using a pen or similar tool (item 2) press in on the top cover release (item 3)
and raise the top cover (item 4).
4 While pressing down on the printhead carrier (item 2), loosen and remove
the printhead screw (item 3) from the printhead (item 1) using a Phillips
screwdriver (item 4).
Note: Printheads are fragile; use extreme care when handling and never use a
sharp object on the surface. If you have questions, contact a qualified
technician or Honeywell technical support before proceeding.
