Hotpoint BZ 89E1 P - Component Replacement and Cleaning Functions

2.UseascrewdrivertoliftupandturnthesmallleversF located on the two
hinges (see diagram).
F
3. Grip the door on the two outer sides and
close it approximately half way. Pull the
door towards you, lifting it out of its slot (see
diagram). To replace the door, reverse this
sequence.
Inspecting the seals
Check the door seals around the oven regularly. If the seals are damaged,
please contact your nearest Service Centre (see Assistance). We recommend
that the oven is not used until the seals have been replaced.
Replacing the light bulb
To replace the oven light bulb:
1. Remove the glass cover of the
lamp-holder.
2. Remove the light bulb and replace
it with a similar one: halogen lamp
voltage230V,wattage25W,capG9.
3. Replace the glass cover (see
diagram).
! Do not touch the light bulb directly with your hands.
!Donotusetheovenlampas/forambientlighting.
Sliding rack kit assembly
To assemble the sliding racks:
1. Remove the two frames, lifting them
away from the spacers A(seegure).
2. Choose which shelf to use with the
sliding rack. Paying attention to the
direction in which the sliding rack is to
beextracted,positionjointB and then
jointC on the frame.
Glass cover
Lamp
Lamp
Holder
compartment
A
B
C
Left
guide rail
Right guide
rail
Direction
of extraction
3. Secure the two frames with the
guide rails using the holes provided
on the oven walls (see diagram). The
holes for the left frame are situated at
the top, while the holes for the right
frame are at the bottom.
4.Finally,ttheframesonthespacers
A.
! Do not place the sliding racks in position 5.
WHEN USING THE MAIN OVEN
YOU MUST ENSURE THAT THE
BASE OF THE CAVITY IS NOT
COVERED WITH ALUMINUM
FOIL, UTENSIL OR ANY OTHER
FORM OF COVERING. FAILURE
TO DO THIS MAY RESULT IN
THE CAVITY BEING DAMAGED.
! ATTENTION
Automatic cleaning with the FAST CLEAN function
With the FAST CLEAN mode, the internal temperature of the oven reaches
500°C. The pyrolytic cycle is activated, burning away food and grime residues.
Dirt is literally incinerated.
Keep children away from the appliance during the automatic cleaning cycle
as surfaces may become very hot. Particles may ignite inside the oven due
to the combustion process. There is no cause for concern: this process is
both normal and hazard-free.
Before initiating the FAST CLEAN mode:
• cleantheovendoor;
• removelargeorcoarsefoodresiduesfromtheinsideoftheovenusinga
dampsponge.Donotusedetergents;
• removeallaccessoriesandtheslidingrackkit(wherepresent);
• donotplaceteatowelsorpotholdersovertheovenhandle.
• turntheSELECTORknobtothe“0”position.
! If the oven is too hot, the pyrolytic cycle may not start. Wait for the oven
to cool down.
! The programme may only be started once the oven door has been closed.
To activate the FAST CLEAN cycle press and hold the
icon for
approximately 4 seconds. The TIMER KNOB may be used to select the
desiredcleaninglevel;therearethreedefaulttimesettingswhichcannot
bemodied.
1. Economy (ECO): turn the knob towards “ ”. Duration 1 hour.
2. Normal (NOR): initial level. Duration 1 hour and 30 minutes.
3. Intensive (INT): turn the knob towards “ ”. Duration 2 hours.
4. Press the
buttontoconrm.
D
GB
13
