Installation
! Please keep this instruction booklet in a safe place for future reference. If
the appliance is sold, given away or moved, please make sure the booklet is
alsopassedontothenewownerssothattheymaybenetfromtheadvice
contained within it.
! Please read this instruction manual carefully: it contains important information
concerning the safe operation, installation and maintenance of the appliance.
Positioning
!Donotletchildrenplaywiththepackagingmaterial;itshouldbedisposed
of in accordance with local separated waste collection standards (see
Precautions and tips).
!Theappliancemustbeinstalledbyaqualiedprofessionalinaccordance
with the instructions provided. Incorrect installation may damage property or
cause harm to people or animals.
Built-in appliances
Useanappropriatecabinettoensurethattheapplianceoperatesproperly:
• thepanelsadjacenttotheovenmustbemadeofheat-resistantmaterial.
• cabinetswithaveneerexteriormustbeassembledwithglueswhichcan
withstand temperatures of up to 100°C.
• toinstalltheovenunder the counter (see diagram) or in a kitchen unit,
the cabinet must have the following dimensions:
590 mm.
595 mm.
22,5 mm.*
20,5 mm.
550 mm.
570 mm.
20 mm.
575-585 mm.
45 mm.
560 mm.
550 mm.
min.
! The appliance must not come into contact with electrical parts once it has
been installed. The indications for consumption given on the data plate have
been calculated for this type of installation.
Ventilation
To ensure adequate ventilation, the back panel of the cabinet must be
removed. It is advisable to install the oven so that it rests on two strips of
wood,oronacompletelyatsurfacewithanopeningofatleast45x560
mm (see diagrams).
560 mm.
45 mm.
Centring and xing
Secure the appliance to the cabinet:
• opentheovendoor;
• slideoutthesidegasketsatthetopuntilthe2xingholesareexposed;
• xtheoventothecabinetusingthe2woodscrews;
• repositionthe2gaskets.
! All parts which ensure the safe operation of the appliance must not be
removable without the aid of a tool.
Electrical connection
Ovens equipped with a three-pole power supply cable are designed to operate
with alternating current at the voltage and frequency indicated on the data
plate located on the appliance (see below).
Fitting the power supply cable
1. Open the terminal board by inserting a
screwdriver into the side tabs of the cover.
Usethescrewdriverasaleverbypushing
it down to open the cover (see diagram).
2. Install the power supply cable by
loosening the cable clamp screw
and the three wire contact screws
L-N- .
Connect the wires to the corresponding
terminals: the Blue wire to the terminal
marked (N), the Brown wire to the terminal
marked(L)andtheYellow/Greenwireto
the terminal marked
(see diagram).
3. Secure the cable by fastening the
clamp screw.
4. Close the cover of the terminal board.
Connecting the supply cable to the mains
Install a standardised plug corresponding to the load indicated on the data
plate (see table).
The appliance must be directly connected to the mains using an omnipolar
switch with a minimum contact opening of 3 mm installed between the
appliance and the mains. The switch must be suitable for the charge indicated
and must comply with current electrical regulations (the earthing wire must not
be interrupted by the switch). The supply cable must be positioned so that it
does not come into contact with temperatures higher than 50°C at any point
(the back panel of the oven, for example).
! The installer must ensure that the correct electrical connection has been
performed and that it is fully compliant with safety regulations.
L
N
N
L
6
GB
