Display assembly subcomponents
NOTE: The display assembly subcomponents are for the HP 215 G1 Notebook PC non-
touchscreen models only. HP Pavilion TouchSmart 11 Notebooks, HP Pavilion 11 Notebooks, and
HP 215 G1 Notebook PC with TouchSmart models are spared at the display assembly only.
Item Component Spare part number
(1) Display bezel 744179-001
(2) Display panel cable (includes webcamera/microphone module cable) 744180-001
(3) Webcamera/microphone module 754263-001
(4) Antenna Kit (includes left and right wireless antenna cables and transceivers) 744177-001
(5) 11.6 inch (29.46 cm) flat display panel, HD WLED AG (1366 x 768) (3.6 mm)
standard viewing angle, non-touchscreen
744182-001
(6) Display Hinge Kit (includes left and right hinges) 744181-001
(7) Display back cover 744178-001
Screw pad and display screws (not illustrated) 744184-001
Display assembly subcomponents 19
