Hard drive
NOTE: The hard drive spare part kit does not include the hard drive bracket, hard drive connector
cable, and screws. These components are included in the Hard Drive Hardware Kit, spare part
number 731424-001.
Description Spare part number
500 GB, 5400 rpm, 7.0 mm 683802-001
320 GB, 5400 rpm, 7.0 mm 645193-001
Before removing the hard drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 33).
5. Remove the service door (see
Service door on page 34).
Remove the hard drive:
1. Disconnect the hard drive connector cable (1) from the system board.
2. Release the hard drive connector cable from the routing channel (2) built into the base
enclosure.
3. Remove the four Phillips PM2.0×2.75 screws (3) that secure the hard drive to the computer.
Component replacement procedures 35
